1) The flooring, with platform, is designed and made to be used exclusively in indoor areas, so that it can be placed only on existing, perfectly flat floors with the tray resting fully on the base surface (in this way, the load-bearing capacity of the platform depends on the floor underneath, since the tray acts solely as a shim).

2)  In the non-slip flooring area for the operator, on which the machine operator can walk wearing DIN EN345, DIN EN346 and DIN EN347 footwear only, make sure the soles of the footwear are in good condition (according to regulations) and that there are no metal chips or scraps under them, so that they will not damage the flooring surface.

3) The under-machine flooring is designed and made to be used exclusively in indoor areas, so that it can be placed only on existing, perfectly flat floors with the tray resting fully on the base surface (in this way, the load-bearing capacity of the tray, where the feet or base of the machine rest, depends on the floor underneath, since the tray acts solely as a shim).

4) N.B. The under-machine flooring will be made so that the feet rest solely on the bottom of the tray and not on the coupling edge or on the connecting strips. If the machine does not have feet it is essential to insert height shims between the bottom of the tray and the base, so that the base of the machine rests solely on the bottom of the tray.

5) The flooring with platforms is connected to the under-machine flooring with special connecting strips.
6) The flooring
, can be used in machine shops and workshops, near to: - cabin machine tools - plastics processing machines - next to work areas and workbenches - packaging machines - industrial machines in general - machine shops - (the trays placed under the machine are for collecting and containing lubricating oil, while those placed outside the perimeter of the machine can act only as containers for the platforms).





N.B.  The flooring can also be installed in front of machines only, with platforms inserted.
          Or it can be installed under machines only, without platforms inserted.
